被清理工件的最大尺寸

              直徑×高         Φ1400×2100mm

     吊鉤

              電動葫蘆型號     CD13-12D

              最大吊重         1       t

              自轉速度         2.8       r/min

              電機功率         1.5     kw

              運行速度         20        m/min

              電機功率         0.75       kw

              升降速度         8         m/min

     拋丸器

              拋丸器型號       Q034zz

              拋丸器數量       3

              葉輪直徑         Φ340     mm

              總拋丸量         3*180     kg/min

              總功率           3*7.5      kw

     提升機、 分離器

               提升量          15         t/h

               皮帶線速度      1.21       m/min

               分離量          25         t/h

               分離區風速      4~5        m/s

               減速機功率      3          kw

清理一鉤工件所需時間

                             鑄件            4～15     min

                             鍛焊件          3～10      min

     彈丸

               首次裝入量       1         t

               直徑             φ0.2~2.0   mm

     風量

               總風量      6000           m3/h

清理室      4500           m3/h

提升機      1500           m3/h

      設備總功率                ≈35      kw

     清理室最大外形尺寸 　　2000 ×2000×3400 mm
